Product characteristics
Combination with KPT main control unit or all-in-one BMS system.
Flexibly applicate in new energy vehicles, energy storage and other fields.
Product Description
| Technical Parameters | Specification | Precision | Remarks |
| Module Working Voltage | 9-36V | / | / |
| Battery Detection Series | 28S | / | / |
| Temperature Detection Numbers | 4 | / | / |
| Single Voltage Detection Range | 0-5V | ±3mV | / |
| Battery Pack Temperature Acquisition Range | -40℃~125℃ | ±1℃ | NTCType |
| Balancing Mode | Passive balance | / | / |
| Balance Current | 150mA | / | / |
| Dimension | 207.5mm*118mm*25.5mm | ||
| Continuously monitor more than 20 fault conditions and report status through CAN, reliable power supply input with short circuit, reverse voltage, overload protection, online CAN upgrade. | |||
