| Technical parameter | specification | remark |
| Module perating voltage | 9-36V | Mains supply |
| Maximum number of units in the system | 56S | / |
| Temperature sensing number | 12 | NTC |
| Range of battery pack temperature collection | -40°C ~ 125°C | NTC |
| Equilibrium mode | Passive equalization | / |
| Equalizing current | 150mA | / |
| Current sampling | ±500A | Hall sensor |
| Current detection accuracy | ≤1%FSR | / |
| SOC accuracy | ≤3% | / |
| Insulation monitoring | Three levels: 0: no fault (>500Ω/V); 1: General fault (100~500Ω/V); 2: Serious fault (<100Ω/V); | / |
| National standard charging | support | / |
| Slow charge | support | / |
| External communication interface | CAN(3 roads) | / |
| High-low edge | 4 high side and 4 low side | / |
| GPRS communication | / | / |
| RS485 communication | / | / |
| Size | 326mm*92mm*25mm | |
