Product Characteristics
High current output
The battery has built-in temperature protection
The battery comes with a power detection port
CAN communication management: SOC management, fault warning
Battery pack safety, long cycle life
High cycle life of the battery pack, in line with the value concept of low carbon, energy saving and environmental protection
Product Parameter
| Nominal Voltage | 48V |
| Nominal Capacity | 50Ah |
| Charging Voltage | 54.75V |
| Charging Current | ≤15A |
| Discharge Current | 100A |
| Transient Discharge Current | 150A |
| Discharge Cut-off Voltage | 30V |
| Internal Resistance Of Finished Product | ≤100mΩ |
| Battery Weight | 30Kg |
| Product Size | 420*300*170mm（Max） |
| Charging Temperature | 0～45℃ |
| Discharge Temperature | -20～60℃ |
| Storage Temperature | -20～35℃ |
| Temperature Protection | 70℃±5℃ |
| Communication Management | CAN |
Lithium Protection | Short circuit protection, over charge protection, over discharge protection, over current protection, temperature protection, balance and so on |
