Product Characteristics
High current output
The battery has built-in temperature protection
The battery comes with a power detection port
CAN communication management: SOC management, fault warning
Battery pack safety, long cycle life
High cycle life of the battery pack, in line with the value concept of low carbon, energy saving and environmental protection
Product Parameter
| Rated Voltage | 48V |
| Nominal Capacity | 40Ah |
| Minimum Capacity | 39V |
| Charging cut-off Voltage | 54.75V |
| Standard Charging Current | 20A |
| Maximum Charging Current | 40A |
| End-off Voltage | 37.5V |
| Standard Discharge Current | 40A |
| Maximum continuous discharge current | 80A |
| OperatingTemperature（℃）charge | 0～45℃ |
| Operating Temperature（℃） discharging | -20～45℃ |
| Internal Resistance | ≤50mΩ |
| Size | L:315mm W:155mm H:265mm |
| Weight | 22kg |
| IP Rating | IP54 |
| Commumication | CAN |
| Storage Temperature | -20～45℃/one month -20～30℃/six month |
| Cycle Life | ≥1500times |
