| Technical parameter | specification | remark |
| Module perating voltage | 9-36V | Mains supply |
| Maximum number of units in the system | 24S | / |
| Temperature sensing number | 4 | NTC |
| Range of battery pack temperature collection | -40°C ~ 125°C | NTC |
| Equilibrium mode | Passive equalization | / |
| Equalizing current | 150mA | / |
| Current sampling | ±500A | Hall sensor |
| Current detection accuracy | ≤1%FSR | / |
| SOC accuracy | ≤3% | / |
| Insulation monitoring | / | / |
| National standard charging | support | / |
| Slow charge | support | / |
| External communication interface | CAN(2 roads) | / |
| High-low edge | 4 high side and 1 low side | / |
| GPRS communication | / | / |
| RS485 communication | 2 road | / |
| Size | 161.5mm*83mm*25.5mm | |
